1 4 - 5 6 E A centrifugal pump is used to pump water at 7 7 deg Ffrom a reservoir whose surface is

14-56E A centrifugal pump is used to pump water at 77\deg Ffrom a reservoir whose surface is 20.0ft above the centerlineof the pump inlet (Fig. P14-56E). The piping system consistsof 67.5ft of PVC pipe with an ID of 1.2 in and negligibleaverage inner roughness height. The length of pipe from thebottom of the lower reservoir to the pump inlet is 12.0ft.There are several minor losses in the piping system: a sharp-edged inlet (K_(L)=0.5), two flanged smooth 90\deg regularelbows ( K_(L)=0.3 each), two fully open flanged globe valves each, PLEASE USE volume flow rate =40 gallon/minute and thanks in advance
image text in transcribed
