8 . 1 . Determine the analytical expression for a step set point change in the fol lowing processes under P - only and PI

8.1. Determine the analytical expression for a step set point change in the fol
lowing processes under P-only and PI feedback control. You should select
values for the tuning constant that give acceptable performance.
b) Example 3.7 with T as the controlled variable, F as the manipulated
variable, and ASP =3\deg C.(Fc is constant.)
EXAMPLE 3.7. Stirred-tank heat exchanger
To provide another simple example of an energy balance, the stirred-tank heat
exchanger in Figure 3.9 is considered.
Goal. The dynamic response of the tank temperature to a step change in the
coolant flow is to be determined.
Information. The system is the liquid in the tank.
Assumptions.
The tank is well insulated, so that negligible heat is transferred to the sur-
roundings.
The accumulation of energy in the tank walls and cooling coil is negligible
compared with the accumulation in the liquid.
The tank is well mixed.
Physical properties are constant.
The system is initially at steady state.
Data. F=0.085m3min;V=2.1m3;Ts=85.4C;=106gm3;Cp=1calgC;
T0=150C;Tcin=25C;Fcs=0.50m3min;Cpc=1calgC;c=106gm3;
a=1.41105calminC;b=0.50
image text in transcribed
