How could I adjust this code to open a 12v linear actuator before opening the garage door? So im wanting the code to receive the command, makes the actuator slide open because it is being used as a lock and then the video and garage door begins.

import RPi.GPIO as GPIO

import MySQLdb

import datetime

import time

import os

import smtplib

from ftplib import FTP

from email.MIMEMultipart import MIMEMultipart

from email.MIMEText import MIMEText

from email.MIMEImage import MIMEImage

from contextlib import closing

from twilio.rest import TwilioRestClient

# =-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=

# VARIABLES

# CHANGE THESE TO YOUR OWN SETTINGS!

# =-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=

# Insert your own account's SID and auth_token from Twilio's account page

twilio_account_sid = "xxxxxxxxxxxxxxxxxxxxxxxxxx"

twilio_auth_token = "yyyyyyyyyyyyyyyyyyyyyyyyyyyyyy"

# The phone number you purchased from Twilio

sTwilioNumber = "+12145551212"

# Gmail information - for informing homeowner that garage activity happened

recipients = ['myemail@gmail.com', 'home_owner_email@gmail.com']

sGmailAddress = "myemail@gmail.com"

sGmailLogin = "GoogleUserName"

sGmailPassword = "GoogleEmailPassword"

sFTPUserName = "WebsiteFTPUsername"

sFTPPassword = "WebsiteFTPPassword"

sFTPHost = "MyWebsite.com"

iNumOpenings = 0

iStatusEnabled = 1

iAuthorizedUser_Count = 0

iSID_Count = 0

sLastCommand = "Startup sequence initiated at {0}. No open requests, yet".format(time.strftime("%x %X"))

sAuthorized = ""

sSid = ""

sSMSSender = ""

GPIO_PIN = 23

GPIO.setmode(GPIO.BCM)

GPIO.setup(GPIO_PIN, GPIO.OUT)

# Unfortunately, you can't delete SMS messages from Twilio's list.

# So we store previously processed SIDs into the database.

lstSids = list()

lstAuthorized = list() # authorized phone numbers, that can open the garage

# Connect to local MySQL database

con = MySQLdb.connect('localhost', 'garage', 'garagepassword', 'GarageDoor')

# Twilio client which will be fetching messages from their server

TwilioClient = TwilioRestClient(twilio_account_sid, twilio_auth_token)

# =-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=

# FUNCTIONS

# =-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=

# This function sends an SMS message, wrapped in some error handling

def SendSMS(sMsg):

try:

sms = TwilioClient.sms.messages.create(body="{0}".format(sMsg),to="{0}".format(sSMSSender),from_="{0}".format(sTwilioNumber))

except:

print "Error inside function SendSMS"

pass

# Once the garage door has begun opening, I want a video of who's coming in. And then, upload the video to my website so I can see it remotely

def TakeVideoAndUpload():

try:

sVideoFile = "Vid.{0}.h264".format(time.strftime("%m-%d-%Y.%I.%M.%S"))

# Give 10 seconds to garage to raise up

time.sleep(10)

# Now take 60 seconds of video, to see who's coming inside

sVideoCommand = "raspivid -w 640 -h 480 -o /home/pi/movies/{0} -t 60000".format(sVideoFile)

os.system(sVideoCommand)

ftp = FTP(sFTPHost,sFTPUserName,sFTPPassword)

ftp.storbinary("stor {0}".format(sVideoFile), open("/home/pi/movies/{0}".format(sVideoFile),'rb'),blocksize=1024)

# It uploaded ok, so delete the video file to avoid clogging up SD card space

os.system("sudo rm /home/pi/movies/{0}".format(sVideoFile))

except:

print "Error inside function TakeVideoAndUpload"

pass

# When doing a STATUS on the Garage SMS Butler, it will capture a screen shot of the garage, so I can see if it's open or closed, from anywhere in the world

def TakePictureAndUpload():

try:

os.system("raspistill -w 640 -h 480 -o /home/pi/pictures/garagepic.jpg")

ftp = FTP(sFTPHost,sFTPUserName,sFTPPassword)

ftp.storbinary("stor garagepic.jpg", open("/home/pi/pictures/garagepic.jpg",'rb'),blocksize=1024)

except:

print "Error inside function TakePictureAndUpload"

pass

# Send a signal to the relay

def OpenGarageDoor():

try:

GPIO.output(GPIO_PIN, GPIO.HIGH)

time.sleep(0.5)

GPIO.output(GPIO_PIN, GPIO.LOW)

except:

print "Error inside function OpenGarageDoor"

pass

# Email the home owner with any status updates

def SendGmailToHomeOwner(sMsg):

try:

connect = server = smtplib.SMTP('smtp.gmail.com:587')

starttls = server.starttls()

login = server.login(sGmailLogin,sGmailPassword)

msg = MIMEMultipart()

msg['Subject'] = "GARAGE: {0}".format(sMsg)

msg['From'] = sGmailAddress

msg['To'] = ", ".join(recipients)

sendit = server.sendmail(sGmailAddress, recipients, msg.as_string())

server.quit()

except:

print "Error inside function SendGmailToHomeOwner"

pass

try:

# Store authorized phone numbers in a List, so we don't waste SQL resources repeatedly querying tables

with closing(con.cursor()) as authorized_cursor:

authorized_users = authorized_cursor.execute("select sPhone from Authorized")

auth_rows = authorized_cursor.fetchall()

for auth_row in auth_rows:

for auth_col in auth_row:

iAuthorizedUser_Count = iAuthorizedUser_Count + 1

lstAuthorized.append(auth_col)

# Store previous Twilio SMS SID ID's in a List, again, so we don't waste SQL resources repeatedly querying tables

with closing(con.cursor()) as sid_cursor:

sid_rows = sid_cursor.execute("select sSid from Door")

sid_rows = sid_cursor.fetchall()

for sid_row in sid_rows:

for sid_col in sid_row:

iSID_Count = iSID_Count + 1

lstSids.append(sid_col)

print "{0} Service loaded, found {1} authorized users, {2} previous SMS messages".format(time.strftime("%x %X"),iAuthorizedUser_Count,iSID_Count)

SendGmailToHomeOwner("{0} Service loaded, found {1} authorized users, {2} previous SMS messages".format(time.strftime("%x %X"),iAuthorizedUser_Count,iSID_Count))

except:

print "{0} Error while loading service, bailing!".format(time.strftime("%x %X"))

if con: con.close() # Not critical since we're bailing, but let's be nice to MySQL

exit(2)

# =-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=

# MAIN GARAGE LOOP

#

# Continuously scan Twilio's incoming SMS list

# =-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=

while (True):

# The TRY block is critical. If we cannot connect to the database, then we could possibly open the garage dozens of times.

# If we can't contact Twilio, again, we could open the garage excessively. Ideally, if any error at all occurs, we need

# to completely bail, and ideally contact the home owner that this application stopped working.

try:

# Only process messages from today (Twilio uses UTC)

messages = TwilioClient.messages.list(date_sent=datetime.datetime.utcnow())

for p in messages:

sSMSSender = p.from_

# Only processed fully received messages, otherwise we get duplicates

if p.status == "received":

if p.sid not in lstSids: # Is it a unique SMS SID ID from Twilio's list?

# Insert this new SID ID into database and List, to avoid double processing

lstSids.append(p.sid)

try:

with closing(con.cursor()) as insert_sid_cursor:

insert_sid_cursor = insert_sid_cursor.execute("insert into Door(sSid) values('{0}')".format(p.sid))

con.commit()

except:

print "Error while inserting SID record to database"

pass

if p.from_ in lstAuthorized: # Is this phone number authorized to open garage door?

if p.body.lower() == "kill":

print "{0} Received KILL command from phone number {1} - bailing now!".format(time.strftime("%x %X"), sSMSSender)

SendSMS("Received KILL command from you. Bailing to terminal now!")

SendGmailToHomeOwner("Received KILL command from phone number {0}. Exiting application!".format(sSMSSender))

exit(3)

if p.body.lower() == "disable":

iStatusEnabled = 0

print "{0} Received STOP command from phone number {1}, now disabled. Send START to restart".format(time.strftime("%x %X"), sSMSSender)

SendSMS("Received STOP command from you. Send START to restart")

SendGmailToHomeOwner("Received STOP command from phone number {0}. Send START to restart".format(sSMSSender))

if p.body.lower() == "enable":

iStatusEnabled = 1

print "{0} Received START command from phone number {1}. Service is now enabled".format(time.strftime("%x %X"), sSMSSender)

SendSMS("Received START command from you. Service is now enabled")

SendGmailToHomeOwner("Received START command from phone number {0}. Service is now enabled".format(sSMSSender))

if p.body.lower() == "status":

if iStatusEnabled == 1:

TakePictureAndUpload()

print "{0} Status requested from {1}, replied".format(time.strftime("%x %X"), sSMSSender)

SendSMS("ENABLED. Status reply: {0}".format(sLastCommand))

else:

print "{0} SERVICE DISABLED! Status requested from {1}, replied".format(time.strftime("%x %X"), sSMSSender)

SendSMS("SERVICE DISABLED! Status reply: {0}".format(sLastCommand))

if p.body.lower() in ("open","close"):

if iStatusEnabled == 1:

iNumOpenings = iNumOpenings + 1

sLastCommand = "Garage door last opened by {0} on {1}".format(p.from_, time.strftime("%x %X"))

print "{0} Now opening garage for phone number {1}".format(time.strftime("%x %X"), sSMSSender)

# OPEN GARAGE DOOR HERE

SendSMS("Command received, and sent to garage door")

print "{0} SMS response sent to authorized user {1}".format(time.strftime("%x %X"), sSMSSender)

OpenGarageDoor()

TakeVideoAndUpload()

SendGmailToHomeOwner("Garage opened from phone {0}".format(sSMSSender))

print "{0} Email sent to home owner".format(time.strftime("%x %X"))

else:

print "{0} Open request received from {1} but SERVICE IS DISABLED!".format(time.strftime("%x %X"), sSMSSender)

else: # This phone number is not authorized. Report possible intrusion to home owner

print "{0} Unauthorized user tried to access system: {1}".format(time.strftime("%x %X"), sSMSSender)

SendGmailToHomeOwner("Unauthorized phone tried opening garage: {0}".format(sSMSSender))

print "{0} Email sent to home owner".format(time.strftime("%x %X"))

except KeyboardInterrupt:

SendGmailToHomeOwner("Application closed via keyboard interrupt (somebody closed the app)")

GPIO.cleanup() # clean up GPIO on CTRL+C exit

exit(4)

except:

print "Error occurred, bailing to terminal"

SendGmailToHomeOwner("Error occurred, bailing to terminal")

GPIO.cleanup()

exit(1)

GPIO.cleanup()
