No explanation needed 1 point In the Capacitance lab, we built the RC circuit below by connecting a resistor R in series with a capacitor

No explanation needed

image text in transcribed
1 point In the Capacitance lab, we built the RC circuit below by connecting a resistor R in series with a capacitor C. Flipping the switch provided 6 V to the capacitor and we measured the voltage over time to watch the capacitor charge. The value of the capacitor was 10 microfarad and we carried out the experiment with two different resistors: 47 k$ and 100 k$2 in order to compare how resistance affected the charging and discharging time. Figure 1 Red SPDT switch + Voltage Probes Black In such an RC circuit, the charging and discharging occur exponentially, so we fit our data to a function of the form A (t) - Ape Bt. How is the time constant T = RC found from this fit equation? O T = T = m O 11

Step by Step Solution

There are 3 Steps involved in it

Step: 1

blur-text-image
