Was wondering if someone. An help answer data analysis question. This is a magnetism lab. Experiment 5 - Magnetic Field of Current in a Coil

Was wondering if someone. An help answer data analysis question. This is a magnetism lab.

image text in transcribed
Experiment 5 - Magnetic Field of Current in a Coil of Wire Magnetism 1. Take a plastic tube and construct the circuit below by wrapping the wire tightly around one end of the tube. Make sure the wire is wound at the very end of the plastic tube. Draw the circuit diagram in your lab report. 2 2. Place a small compass near the end of the coiled wire in the center of the coil. 3. Close the switch and using the compass. determine the direction of the magnetic field in the center of the coil. Record your findings in your lab report. 4. Reverse the battery leads to change the direction of the current and determine the direction of the magnetic field in the center of the coil. Record in your lab report. Data Analysis/Conclusion 5. Use right-hand rule #2 to determine the direction of the magnetic field in the center of the coil? Draw a picture of the direction of the magnetic field for both directions of the current. Does the direction match your measurement? If not, redo your experiment
