Could you please explain this? A multiloop circuit is shown in the figure. Some circuit quantities are not labeled. It is not necessary to solve

Could you please explain this?

image text in transcribed
A multiloop circuit is shown in the figure. Some circuit quantities are not labeled. It is not necessary to solve the entire circuit. The current 12 , /1 , and & is closest to 11 Q 13 Q M + 6.0 V + 0.6 A 150 17.0 V 0.3 A + 190 30 0 W + 0.4 A 25 0 23 12 11.0 V To.5 A + 21 2

Step by Step Solution

There are 3 Steps involved in it
