Programming Task $2$

Published: Dec $6,2023.$ Due: Jan $2,2023$ by midnight.

Consider the following set of processes:

$\backslash$table$[[$Process$,$Arrival Time,Burst Time,$\backslash$table$[[$Comes back$],[$after$]],$Priority$],[$P$1,0,10,2,3],[$P$2,1,8,4,2],[$P$3,3,14,6,3],[$P$4,4,7,8,1],[$P$5,6,5,3,0],[$P$5,7,4,6,1],[$P$7,8,6,9,2]]$

Once each process is done processing its "Burst Time", it goes to the waiting queue, then "Comes back" to the ready queue after the time shown.

You are required to simulate the CPU schedule for a period of $200$ time units.

For each of the following scheduling algorithms, your program must show the Gantt chart, average waiting time, and average turnaround time.

$1-$ First Come First Served.

$2-$ Shortest Job First.

$3-$ Shortest Remaining Time First.

$4-$ Round Robin, with $q=5$

$5-$ Preemptive Priority Scheduling, with aging; where priority is decremented by $1$ if the process remains in the ready queue for $5$ time units.

$6-$ Non$-$preemptive Priority Scheduling, with aging; where priority is decremented by $1$ if the process remains in the ready queue for $5$ time units.

For this assignment, you may use any programming language of your choosing.

Hint: You should create a process that initially creates the $7$ processes, and continuously updates the status of the processes, and another process that schedules those processes, and plots the result

Write it in see program
