1. Build the half adder circuit. Test the circuit and ensure that the truth table is correct. Write the Boolean functions for sum and carry beside the circuit Open a new circuit window and test your HalfAdder device/sub-circuit. Here is a testing circuit for your reference. HPfadder { Hand-In The "Half Adder" circuit and the HalfAdder device/sub-circuit testing circuit e Boolean functions for Sum and Carry 2. As mentioned in the notes, a fulladder can be designed by using two "Half Adder" devices/sub-circuits and one additional OR gate Hint -- the sum of the carries out of the two hair adders) Build and test your Fulladder circuit with the truth table Write the Boolean functions for sum and the carry beside the circuit Hand in The fulladder circuit using two "Half Adder devices and one additional OR gate Boolean functions for Sum and Carry for the full adder 3. A half subtractor subtracts two bits, x and y producing their difference d. it also has an output b to specify if a 1 has been borrowed from the next higher position. The truth table is given below. Draw the "Half Subtractor" circuit, then, test the truth table. Write the Boolean function for d and b beside the circuit Input Output X Y b d 0 000 0 TO 01 1 0 0 Hand-in aThe the "Half Subtractor Circuit Boolean functions for borrow (b) and difference (a) 4. Using the property that Foy..y Show that a hair subtractor can be implemented using a "Haif Adder device and two inverter gates Build and test this circuit with the truth table Write the expressions of the difference and the borrow beside the circuit Hand-In The half subtractor circuit using the Hall Adder device and two NOTES Boolean functions for Difference and Borrow will be slightly different from 3, because of inverters-consider what is going into the box and what is coming out of the box) Usodra Thdeed - Bing Workday . The half subtractor circuit using the "Half Adder" device and two NOT's Boolean functions for Difference and Borrow (will be slightly different from 3, because of inverters--consider 5. A full subtractor can be built using two "Half Subtractor'devices and an OR gate. Design and test a full subtractor (schematic diagram and truth table shown below). Write the expressions of the difference and the borrow beside the circuit. Input Output bi bil VALO OOD 11 1 LOR 00 1 X 0 FOTO NE LO 0 0 0 LA Hand-in The full subtractor circuit using two "Half Subtractor devices and an OR gate Boolean functions for Difference and Borrow 6. Show that a fult subtractor can be implemented using a fan Adder device and two inverter gates You have a "Full Adder" circuit n part 2 already Build and test your circuit with the truth table, Write the expressions of the difference and the borrow beside the circuit Hand in The full subtractor circuit using "Full Adder "device and two NOT gates Boolean functions for Difference and Borrow (a little different from part 5 because of the inverters) 7. Build a 4-bit parallel adder by using four "Full Adder" devices. For this, you will use the "Full Adder device from your circuit in the previous step Build and test your circuit with the examples 1 gere 033 0011 de emples your choice Hand in The 4-bit ParaseAdder Circuit using Full Adder devices sob circuts with the above to examples and another one of your choice Inputs are provided with the one bit input devices and the outputs will be displayed with the one bit output devices
