Please help me answer all the questions on this page and thoroughly explain how you got them Use the following image to answer questions 4-6:

Please help me answer all the questions on this page and thoroughly explain how you got them

image text in transcribed
Use the following image to answer questions 4-6: below. Three long, straight wires separated by 0.10 m carry currents of 18 A and 6 A in the directions shown 18 A ISA out Ou wire 1 -0.10 m -0.10 m- 4. Determine the magnitude of the Total magnetic field at point P. (show your work) Bin 5. what is the direction of the Total Magnetic Field at point P in the image above? a. Toward the left b. Toward the right c. Toward the top of the page d. Toward the bottom of the page e. Out of the page F. Into the page 6. What is the direction of the magnetic force on wire 1? a. Toward the left b. Toward the right C . Toward the top of the page d. Toward the bottom of the page Out of the page f . Into the page

Step by Step Solution
