Question: Question 4 The Bode plots of the open loop transfer function of a is shown in Fig Q 4 . NOVIDEC 2 0 2 4

Question 4
The Bode plots of the open loop transfer function of a is shown in Fig Q4.
NOVIDEC 2024
dback system
(1) Find the system type with supporting reason.
(2) Calculate the static error constant and steady state error, if the input is unit velocity signal.
(3) Find the stability margins (gain margin and phase margin.
(4) Estimate the system damping ratio and overshoot.
Bode Diagram
Fig. Q4.
